Typical contact resistance:≤1 mΩ
Insulation resistance:≥2000 MΩ
Flame class:UL94-V0
Contaction type:Screw
Contaction Size/number of contact:Φ2.6*3
Ambient temperature range:-40℃ until +65℃
Suitable cable cross sections:2.5~6.0 mm²
Suitable cable OD Max.:Φ18mm
Standard:UL2238/EN 61984/CE



Specification Material
Box

Main body:PPE






Connector side


Environmental/Reliability



Degree of protection:IP67

Electrical Specification

Rated current:Max.35A

Overvoltage category:4kV
Rated impulse voltage:500V AC

Others
Contact method:Copper,Tin plated
